Design of a Networked Tracking Control System With a Data-based Approach

Shiwen Tong; Dianwei Qian; Xiaoyu Yan; Jianjun Fang; Wei Liu

doi:10.1109/JAS.2018.7511093

Volume 6 Issue 5

Sep. 2019

IEEE/CAA Journal of Automatica Sinica

JCR Impact Factor: 15.3, Top 1 (SCI Q1)

CiteScore: 23.5, Top 2% (Q1)
