Neural Network Based Terminal Sliding Mode Control for WMRs Affected by an Augmented Ground Friction With Slippage Effect

Ming Yue; Linjiu Wang; Teng Ma

doi:10.1109/JAS.2017.7510553

Volume 4 Issue 3

Jul. 2017

IEEE/CAA Journal of Automatica Sinica

JCR Impact Factor: 15.3, Top 1 (SCI Q1)

CiteScore: 23.5, Top 2% (Q1)
Google Scholar h5-index: 77， TOP 5

Turn off MathJax

Article Contents

Article Navigation > IEEE/CAA Journal of Automatica Sinica > 2017 > 4(3): 498-506

Ming Yue, Linjiu Wang and Teng Ma, "Neural Network Based Terminal Sliding Mode Control for WMRs Affected by an Augmented Ground Friction With Slippage Effect," IEEE/CAA J. Autom. Sinica, vol. 4, no. 3, pp. 498-506, July 2017. doi: 10.1109/JAS.2017.7510553

Citation:

Ming Yue, Linjiu Wang and Teng Ma, "Neural Network Based Terminal Sliding Mode Control for WMRs Affected by an Augmented Ground Friction With Slippage Effect," IEEE/CAA J. Autom. Sinica, vol. 4, no. 3, pp. 498-506, July 2017. doi: 10.1109/JAS.2017.7510553

Citation:

PDF( 698 KB)

Neural Network Based Terminal Sliding Mode Control for WMRs Affected by an Augmented Ground Friction With Slippage Effect

doi: 10.1109/JAS.2017.7510553

Ming Yue^{1
,
,},
Linjiu Wang^2
,,
Teng Ma^1
,

1.
School of Automotive Engineering, Dalian University of Technology, Dalian 116024, China
2.
State Key Laboratory of Robotics and System, Harbin Institute of Technology, Harbin 150001, China

Funds:

the National Natural Science Foundation of China 61573078

the National Natural Science Foundation of China 61573147

the International S & T Cooperation Program of China 2014DFB70120

the State Key Laboratory of Robotics and System SKL RS2015ZD06

More Information

Abstract

Abstract

Wheeled mobile robots (WMRs) encounter unavoidable slippage especially on the low adhesion terrain such that the robots stability and accuracy are reduced greatly. To overcome this drawback, this article presents a neural network (NN) based terminal sliding mode control (TSMC) for WMRs where an augmented ground friction model is reported by which the uncertain friction can be estimated and compensated according to the required performance. In contrast to the existing friction models, the developed augmented ground friction model corresponds to actual fact because not only the effects associated with the mobile platform velocity but also the slippage related to the wheel slip rate are concerned simultaneously. Besides, the presented control approach can combine the merits of both TSMC and radial basis function (RBF) neural networks techniques, thereby providing numerous excellent performances for the closed-loop system, such as finite time convergence and faster friction estimation property. Simulation results validate the proposed friction model and robustness of controller; these research results will improve the autonomy and intelligence of WMRs, particularly when the mobile platform suffers from the sophisticated unstructured environment.
- Ground friction,
- radial basis function (RBF) neural network (NN),
- slippage effect,
- terminal sliding mode control (TSMC),
- wheeled mobile robot (WMR)
