Twisting Sliding Mode Control of an Electrostatic MEMS Micromirror for a Laser Scanning System

Hui Chen; Zhendong Sun; Weijie Sun; John Tze Wei Yeow

doi:10.1109/JAS.2016.7510223

Volume 6 Issue 4

Jul. 2019

IEEE/CAA Journal of Automatica Sinica

JCR Impact Factor: 15.3, Top 1 (SCI Q1)

CiteScore: 23.5, Top 2% (Q1)
