Fengning Zhang, "High-speed Nonsingular Terminal Switched Sliding Mode Control of Robot Manipulators," IEEE/CAA J. Autom. Sinica, vol. 4, no. 4, pp. 775-781, Oct. 2017. doi: 10.1109/JAS.2016.7510157
Citation: Fengning Zhang, "High-speed Nonsingular Terminal Switched Sliding Mode Control of Robot Manipulators," IEEE/CAA J. Autom. Sinica, vol. 4, no. 4, pp. 775-781, Oct. 2017. doi: 10.1109/JAS.2016.7510157
shu

High-speed Nonsingular Terminal Switched Sliding Mode Control of Robot Manipulators

doi: 10.1109/JAS.2016.7510157

  • Department of Physics, Jining Normal University, Wulanchabu 012000, China

Funds:

the Research Program of Science and Technology at Universities of Inner Mongolia Autonomous Region NJZY13279

More Information
    Abstract
  • This paper proposes a high-speed nonsingular terminal switched sliding mode control (HNT-SSMC) strategy for robot manipulators. The proposed approach enhances the control system performance by switching among appropriate sliding mode controllers according to different control demands in different regions of the state space. It is shown that the highspeed nonsingular terminal switched sliding mode (HNT-SSM) which is the representation of different control demands and enforced by the HNT-SSMC has the property of global highspeed convergence compared with the nonsingular fast terminal sliding mode (NFTSM), and provides the global non-singularity. The simulation study of an application example is carried out to validate the effectiveness of the proposed strategy.



    • FullText(HTML)
  • loading
    • Recommended by Associate Editor Qinglai Wei
    References(26)
  • [1]
    L. Cheng, Z. G. Hou, and M. Tan, "Adaptive neural network tracking control for manipulators with uncertain kinematics, dynamics and actuator model, " Automatica, vol. 45, no. 10, pp. 2312-2318, Oct. 2009. http://www.sciencedirect.com/science/article/pii/S0005109809002982
    [2]
    L. Cheng, Y. Z. Lin, Z. G. Hou, M. Tan, J. Huang, and W. J. Zhang, "Adaptive tracking control of hybrid machines: A closed-chain five-bar mechanism case, " IEEE/ASME Trans. Mechatron. , vol. 16, no. 6, pp. 1155-1163, Dec. 2011. http://ieeexplore.ieee.org/document/5625912/
    [3]
    Y. Q. Gao, F. Y. Wang, and Z. Q. Zhao, Flexible Manipulators:Modeling, Analysis and Optimum Design. New York:Academic Press, 2012, pp. 185-249.
    [4]
    L. Cheng, Z. G. Hou, M. Tan, and W. J. Zhang, "Tracking control of a closed-chain five-bar robot with two degrees of freedom by integration of an approximation-based approach and mechanical design, " IEEE Trans. Syst. Man Cybern. B Cybern. , vol. 42, no. 5, pp. 1470-1479, Oct. 2012.
    [5]
    Y. Feng, X. H. Yu, and Z. H. Man, "Non-singular terminal sliding mode control of rigid manipulators, " Automatica, vol. 38, no. 12, pp. 2159-2167, Dec. 2002. http://dl.acm.org/citation.cfm?id=2236784
    [6]
    X. Wang and J. Zhao, "Switched adaptive tracking control of robot manipulators with friction and changing loads, " Int. J. Syst. Sci., vol. 46, no. 6, pp. 955-965, May 2015. doi: 10.1080/00207721.2013.801098
    [7]
    H. Lin and P. J. Antsaklis, "Stability and stabilizability of switched linear systems: A survey of recent results, " IEEE Trans. Automat. Control, vol. 54, no. 2, pp. 308-322, Feb. 2009.
    [8]
    Q. S. Xu, "Design and smooth position/force switching control of a miniature gripper for automated microhandling, " IEEE Trans. Industr Inform., vol. 10, no. 2, pp. 1023-1032, May 2014. doi: 10.1109/TII.2013.2290895
    [9]
    F. Blanchini, P. Colaneri, D. Casagrande, P. Gardonio, and S. Miani, "Switching gains for semiactive damping via nonconvex Lyapunov functions, " IEEE Trans. Control Syst. Technol. , vol. 22, no. 2, pp. 721-728, Mar. 2014. http://ieeexplore.ieee.org/document/6516586/
    [10]
    G. S. Deaecto, M. Souza, and J. C. Geromel, "Discrete-time switched linear systems state feedback design with application to networked control, " IEEE Trans. Automat. Control, vol. 60, no. 3, pp. 877-881, Mar. 2015. http://ieeexplore.ieee.org/xpls/icp.jsp?arnumber=6860315
    [11]
    X. D. Zhao, P. Shi, and L. X. Zhang, "Asynchronously switched control of a class of slowly switched linear systems, " Syst. Control Lett. , vol. 61, no. 12, pp. 1151-1156, Dec. 2012. http://www.sciencedirect.com/science/article/pii/S0167691112001752
    [12]
    Y. Feng, F. L. Han, and X. H. Yu, "Chattering free full-order slidingmode control, " Automatica, vol. 50, no. 4, pp. 1310-1314, Apr. 2014. http://www.sciencedirect.com/science/article/pii/S0005109814000375
    [13]
    J. J. Slotine and W. P. Li, Applied Nonlinear Control. Englewood Cliffs, NJ:Prentice-Hall, 1991, pp. 276-310.
    [14]
    G. Bartolini and E. Punta, "Multi-input sliding mode control of nonlinear uncertain non-affine systems with mono-directional actuation, " IEEE Trans. Automat. Control, vol. 60, no. 2, pp. 393-403, Feb. 2015. http://www.sciencedirect.com/science/article/pii/S1474667016301719
    [15]
    X. G. Yan, S. K. Spurgeon, and C. Edwards, "Memoryless static output feedback sliding mode control for nonlinear systems with delayed disturbances, " IEEE Trans. Automat. Control, vol. 59, no. 7, pp. 1906-1912, Jul. 2014. http://ieeexplore.ieee.org/document/6690208/
    [16]
    M. Rubagotti, A. Estrada, F. Castanos, A. Ferrara, and L. Fridman, "Integral sliding mode control for nonlinear systems with matched and unmatched perturbations, " IEEE Trans. Automat. Control, vol. 56, no. 11, pp. 2699-2704, Nov. 2011. http://ieeexplore.ieee.org/document/5873128/
    [17]
    O. Barambones and P. Alkorta, "Position control of the induction motor using an adaptive sliding-mode controller and observers, " IEEE Trans. Industr. Electron. , vol. 61, no. 12, pp. 6556-6565, Dec. 2014. http://ieeexplore.ieee.org/xpls/icp.jsp?arnumber=6786033
    [18]
    R. M. Zhang, L. Dong, and C. Y. Sun, "Adaptive nonsingular terminal sliding mode control design for near space hypersonic vehicles, " IEEE/CAA J. Automat. Sin. , vol. 1, no. 2, pp. 155-161, Apr. 2014. http://ieeexplore.ieee.org/document/7004545/
    [19]
    J. M. Zhang, C. Y. Sun, R. M. Zhang, and C. S. Qian, "Adaptive sliding mode control for re-entry attitude of near space hypersonic vehicle based on backstepping design, " IEEE/CAA J. Automat. Sin. , vol. 2, no. 1, pp. 94-101, Jan. 2015. http://ieeexplore.ieee.org/document/7032910/
    [20]
    C. X. Mu, Q. Zong, B. L. Tian, and W. Xu, "Continuous sliding mode controller with disturbance observer for hypersonic vehicles, " IEEE/CAA J. Automat. Sin. , vol. 2, no. 1, pp. 45-55, Jan. 2015. http://ieeexplore.ieee.org/document/7032905/
    [21]
    H. Ríos, S. Kamal, L. M. Fridman, and A. Zolghadri, "Fault tolerant control allocation via continuous integral sliding-modes: A HOSMObserver approach, " Automatica, vol. 51, pp. 318-325, Jan. 2015. http://www.sciencedirect.com/science/article/pii/S000510981400466X
    [22]
    T. Bernardes, V. F. Montagner, H. A. Grundling, and H. Pinheiro, "Discrete-time sliding mode observer for sensorless vector control of permanent magnet synchronous machine, " IEEE Trans. Industr. Electron. , vol. 61, no. 4, pp. 1679-1691, Apr. 2014. http://ieeexplore.ieee.org/document/6529105/
    [23]
    I. Nagesh and C. Edwards, "A multivariable super-twisting sliding mode approach, " Automatica, vol. 50, no. 3, pp. 984-988, Mar. 2014. http://www.sciencedirect.com/science/article/pii/S0005109813005918
    [24]
    Z. H. Man, A. P. Paplinski, and H. R. Wu, "A robust MIMO terminal sliding mode control scheme for rigid robotic manipulators, " IEEE Trans. Automat. Control, vol. 39, no. 12, pp. 2464-2469, Dec. 1994. http://ieeexplore.ieee.org/xpls/abs_all.jsp?arnumber=362847
    [25]
    X. H. Yu and Z. H. Man, "Fast terminal sliding-mode control design for nonlinear dynamical systems, " IEEE Trans. Circuits Syst. I Fundam. Theory Appl. , vol. 49, no. 2, pp. 261-264, Feb. 2002. http://ieeexplore.ieee.org/xpls/icp.jsp?arnumber=983876
    [26]
    H. Li, L. H. Dou, and Z. Su, "Adaptive nonsingular fast terminal sliding mode control for electromechanical actuator, " Int. J. Syst. Sci. , vol. 44, no. 3, pp. 401-415, Aug. 2013. http://www.ams.org/mathscinet-getitem?mr=3000755
